D4 202

D4 202 ETH

Printing Method:

Direct thermal / Thermal transfer

Resolution:

203 dpi

Printing speed:

5 ips

Print Width:

104 mm

Sensors:

Moveable see-through / reflective sensor, Ribbon sensor, Cover open sensor

RAM Memory:

128 MB

Display:

Colorful 2.8" backlight LCD display, 240 × 320 dots

Control Panel:

4 multi-functional keys

Interfaces:

USB port

USB master port

Serial port

Eternet port 10/100Mbps (optional)

USB port

USB master port

Serial port

Eternet port 10/100Mbps on board

Media:

MMaximum label width: 110 mm

Minimum label width: 15 mm

Maximum roll diameter: 127 mm

Core diameter: 25.4 mm

Media thickness: 0.06 mm to 0.2 mm

Media type: Continuous, die-cut, tag, fan-fold, black mark

Ribbon:

Max length: 100 m

Width: 25.4 mm to110 mm

ID:12.7 mm

Ribbon type: Wax, wax/resin, resin

Emulation Language:

PEPL, PDPL, PZPL

Supported 1D/2D Barcodes:

Code39 stand or extended, Code39 with check digit, Code93, Code128 UCC, Code128 Auto A,B,C mode, EAN8, EAN8/13 2&5 digit add-on, EAN13, Interleaved 2 of 5, Interleaved 2 of 5 with check digit, Interleaved with human readable check digit, UCC/EAN 128, UPC-A, UPC-A 2&5 digit add-on, UPC-E, UPC-E 2&5 digit add-on, UPC Interleaved 2 of 5, Code 11 PDF417, Maxicode, Data Matrix, QR code

Fonts:

5 internal expandable bitmap fonts (alpha-numeric)

2 internal expandable bitmap fonts (numeric only)

Downloadable soft font

4 directions: 0, 90, 180, 270 degrees

Image:

PEPL: PCX, Direct binary graphic

Options:

Peeler kit, Cutter i Ethernet modul

Power:

Input: 100 to 240 V, 1.8 A, 50~60 Hz

Output: 24 V, 2.5 A

Audio:

Beep sound when error occurs

Operation temperature:

5 ºC to 45ºC

Dimensions:

263 mm (L) × 200 mm (W) × 188 mm (H)

Weight:

2kg

Warranty:

24 months
